Gas Analyzer | Enerac 500 | 1st in US

ENERAC™ invented the first electronic portable multi-parameter combustion gas analyzer in 1979 (in the U.S.A.). We still service this analyzer today as well as all others ENERAC has manufactured. The ENERAC™ Model 500 is a low-cost, easy to use (no technical expertise needed, etc.) portable combustion efficiency emissions gas analyzer.

Affordable Compliance-Level Portable Combustion Gas Analyzer

The ENERAC™ 500 gas analyzer is perfect for both determining the efficiency of a combustion source as well as collecting advanced emissions data for internal use or for local, state and federal emissions reporting requirements (a compliance-level portable combustion analyzer).

Boilers, Burners, Engines, Turbines, Generators, Kilns, Dryers, Heaters, Ovens & More

The ENERAC™ 500 is perfect for testing various combustion sources, such as boilers, burners, engines, turbines, generators, kilns, dryers, heaters and ovens, just to name a few.

A Field Workhorse Upgradeable to Meet Your Needs Today… &

Tomorrow Equally, with a simple combustion efficiency test or a more advanced combustion emissions test, the ENERAC™ 500 is designed to provide years of trouble-free service. It is flexible enough to be tailored to meet your specific needs, yet simple enough to be completely maintained in the field. Advanced design, rugged construction and an impressive array of options are its hallmark. Constructed as a field workhorse, the ENERAC™ 500 can be upgraded at any time (adding options to the same unit) to meet your changing needs.

A Gas Analyzer that’s Affordable & Comprehensive

The ENERAC™ 500 provides a comprehensive range of automatic emissions calculations (grams/brake horsepower hour; pounds/ million Btu) advanced Enercom windows software, two-way communications and factory support. From low NOx burners (0.1 ppm NOx resolution) to large rich burn engines (5,000ppm NOx/20,000ppm CO,) the ENERAC™500 is designed to help you meet your needs of various monitoring applications at an affordable price.

MODEL 500 GAS ANALYZER PHYSICAL SPECIFICATIONS:

1. CASE: 9.75” x 4” x 2.75” Aluminum case with magnetic support.
2. WEIGHT: 3 lbs.
3. PROBE: 9” L x 3.8” OD (other lengths available) Inconel steel stack probe. Probe housing connects to instrument via a 10 ft. Viton hose (other lengths available) and water trap and thermoelectric condenser. Maximum continuous temperature: 2000 F.
ELECTRICAL POWER:
1.BATTERY: 4-6 VDC. Rechargeable NiMH (included) or 4 disposable AA alkaline cells. Approx. 6-8 hours operating time (1.5 hours with T’cooler)
2.AC CHARGER: 120/240v. 60/50 hz. 9vdc output
DISPLAY: Four line by 16 character Liquid Crystal Display with backlight illumination.
PRINTER: Internal 2” thermal printer.
DATA STORAGE: Internal: 400 individually selectable buffers hold one complete set of measurements each in non-volatile memory. Buffer contents can be sent to printer or serial port. Data is stored by pressing the STORE key or automatically on a periodic basis.
COMMUNICATIONS: Serial Port (RS-232C port) settings: 9600,N,8,1 USB Port Bluetooth Wireless (Class 1 – 100m)
FUELS: 15 Fuels: #2 Oil, #4 Oil, #6 Oil, Natural Gas, Anthracite, Bituminous, Lignite, Wood (50% H2O), Wood (0% H2O), Kerosene, Propane, Butane, Coke Oven Gas, Blast Furnace & Sewer Gas. Custom fuels available on request or by customer programming using ENERCOM software

Enerac 500 Gas Analyzer: Durable, Low Cost, Portable, Upgradeable

The Enerac Model 500 is a durable, affordable, easy-to-operate portable gas analyzer that is upgradeable to meet your needs now, and in the future. Contact us at 1-800-695-3637 or sales@enerac.com to learn more about the Enerac 500 portable multi-parameter emissions gas analyzer.

Emissions Monitoring
Equipment-M500

A NEW GENERATION IN PORTABLE
EMISSIONS MONITORING EQUIPMENT

blankspace
enerac_500_tab_banner

INTRODUCTION

INTRODUCTION

The Enerac 500 provides a comprehensive range of automatic emissions calculations, advanced Enercom Windows Software, two-way communications and factory support. From low NOx burners, (0.1ppm NOxresolution) to large rich burn engines (5,000ppm (NOx)/20,000ppm CO) the Enerac 500 is designed to help meet your needs of various monitoring applications at an affordable price.

The Enerac 500 handheld combustion efficiency emissions analyzer, is our newest, low cost, Emissions-Monitoring System, utilizing standard electrochemical sensors. It is designed to help you meet the challenges of a rapidly changing regulatory environment. It is easy to use, comprehensive (O2-CO-NO-NO2-(NOx), SO2, Combustibles, Stack Temperature, Draft), and flexible.

  • A micro-sized Combustion-Efficiency analyzer and Emissions-Monitoring System
  • Thermoelectric Condenser / Peltier Cooler (sample conditioning system for proper detection and measurement of NO2 and/or SO2 gasses
  • Powered by 4xAA Rechargeable batteries
  • Built-in Thermal Printer: 2″ Character-type
  • Our Enercom Windows Software included
  • USB and Serial Ports included. Bluetooth Wireless (optional)

RUGGED

RUGGED

The Enerac 500 is designed for years of trouble-free service. Housed in a rugged, lightweight aluminum case, its modular design allows end-users the ability to replace a battery or sensor, in a matter of seconds. Reducing both downtime and costs.

  • Rugged lightweight aluminum case
  • Work-horse of the industry
  • Won’t warp or crack like plastic models
  • Small, lightweight and tough
  • 2 Year Warranty
  • 24 Hour Service
  • Best service and support in the industry


COMPREHENSIVE

COMPREHENSIVE

The Enerac 500 provides an extensive range of data management, and support options. It not only (automatically) performs complicated emission calculations, it can even allow the user the ability to identify specific data sets with a specific customer, dramatically reducing retrieval and processing costs.

Enerac 500 is compatible with Enerac’s advanced Enercom for Windows ™ software. All parameters can be continuously displayed; Minimum, Maximum, Averages and Standard Deviations calculated; Multiple plots and graphs can be viewed or printed. With the Enercom software, data management and report writing is now a snap. With the Enerac 500, help is never more than a phone call or email away.


AFFORDABLE

AFFORDABLE

With all these capabilities the Enerac 500 is surprisingly affordable.

  • Buy only what you need and add options later
  • Always upgradeable (anytime)!
  • Free software and accessories
  • Receive a generous trade-in allowance on your old analyzer
  • Loaners available at no charge.


COMPLIANCE LEVEL

COMPLIANCE LEVEL

The Enerac 500 can be configured to a compliance-level analyzer with addition of several key features. The Enerac 500 has the ability to produce Total NOx data for one. With both the NO and NO2 sensors Total NOxis obtained (NOx)=NO+NO2 on stationary combustion sources). The ability to also configure the 500 with High Sensativity sensors allows extreme accuracy over the sensors shorter range etc. Additionally, the 500 has the option to have the Thermoelectric Condenser (also called Peltier Cooler) option installed. This is a sample conditioning system (usually found on our competitors larger more expensive units) essential for proper NO2 and or SO2 gas detection and measurement. With the final addition of the viton hose, sample quality is maintained and compliance level data obtained. Therefore, the Enerac 500 is perfect for meeting your local, state and federal regulatory emissions compliance requirements.

  • Free data collection software
  • Time-stamped internal data storage
  • Total NOx (NO and NO2)
  • High Sensitivity / Low Range Sensors Available
  • Viton and Teflon hose options
  • Sample Conditioning System (for proper NO2 and/or SO2 gas detection and measurement)
  • Field replaceable sensors
  • Easy field calibrations (if desired)
  • Comply with local, state and federal emissions requirements

In a world of downsizing, and increasing workloads, the Enerac 500 can help you simplify your job. With a broad array of available options, the Enerac 500 will provide you with the capabilities you need, when you need them, all within your budget.



Enerac 500

enerac_500_tab_banner2
blankspace
  • Hand-Held Analyzer
  • Light-Weight Aluminum Case
  • 3 lbs
  • Powered by 4 X AA Rechargeable Batteries
  • Back up alkaline battery adapter
  • Total NOx Capabilities (NO + NO2)
  • Sample Conditioning System (optional)
  • (Thermoelectric Condenser/Peltier Cooler. Essential for proper NO2 and/or SO2 gas detection and measurement)
  • Standard electrochemical single range sensor
  • Optional Smoke Probe
  • RS 232 Serial Port (std), Blue-tooth (std)
  • Built-in Thermal Printer: 2″ Character-type
  • 400 sets of internal data storage buffers
  • Free Enercom Software

Enerac 700

700
blankspace
  • Hand-Held Analyzer
  • Light-Weight Aluminum Case
  • 6 lbs
  • Powered by 4 or 6 X D Rechargeable Batteries
  • Total NOx Capabilities (NO + NO2)
  • Sample Conditioning System (standard)
  • (Thermoelectric Condenser/Peltier Cooler. Essential for proper NO2 and/or SO2 gas detection and measurement)
  • Advanced electrochemical SEM(TM) dual range sensors
  • Optional 3-channel (NDIR) Infrared bench for measuring CO, CO2, & CxHy hydrocarbons.
  • Optional Velocity Probe (Mass Emissions)
  • Optional Smoke Probe
  • RS 232 Serial Port (std), Blue-tooth (std)
  • Built-in Thermal Printer: 2″ Graphic-type
  • 500 sets of internal data storage buffers
  • Free Enercom Software

To find out just how easy it is to own an Enerac 700 – call us at (800) 695-3637 OR
